StoreWALL Standard Duty Wall Panels - Barnwood Grey (1219mm)

StoreWALL Standard Duty panels in Barnwood Grey — a textured wood-grain finish in grey tones that brings the character of weathered timber to a garage or workshop wall, with none of the maintenance. Four panels per carton, 1.48sqm coverage, 56kg rated with SD InstallStrips.

Specifications

Specification	Detail
SKU	4-SD-BWG-12
Colour	Barnwood Grey
Panels per carton	4
Panel dimensions	1219mm L × 304.8mm H × 16.7mm thick
Carton coverage	1.48sqm (1.219m wide × 1.219m high — 4 rows of panels)
Material & construction	Solid extruded PVC with a textured wood-grain (imitation) surface finish in grey tones. Waterproof, mould-resistant, impact-resistant.
Groove pitch	76mm on-centre — standard slatwall
Grooves per panel	4 grooves per panel
Weight capacity — at panel surface	56kg per 1219mm panel (with SD InstallStrips installed)
Weight capacity — 10cm from wall	26kg per 1219mm panel (with SD InstallStrips installed)
Without InstallStrips	Weight capacity drops ~75% if installed face-screw only. Always use SD InstallStrips for rated capacity.
InstallStrips required	1 × Standard Duty InstallStrip (914mm) per panel — 4 per carton. Sold separately.
Screws required	7g × 40mm (timber studs) or 5mm × 40mm nylon anchors (brick/concrete). Not included.
Accessory compatibility	All StoreWALL CamLok accessories. Also compatible with any standard 76mm on-centre slatwall accessory.
Colour note	Barnwood Grey simulates weathered timber — like real wood, natural variation in grain pattern and tone between panels is expected and intentional.
Shipping	Ships via courier Australia-wide. Calculated at checkout by postcode.
Warranty	5 years — panels and InstallStrips. 5 years — accessories.

Barnwood Grey — character and texture without the upkeep

Barnwood Grey sits between a neutral grey and a timber look — it has the warmth and texture of weathered barn timber, rendered in grey tones that suit garage and workshop environments without looking overly decorative. It reads as natural and grounded rather than industrial, which makes it a good choice when the garage connects to living areas or when the space is used for purposes beyond tool storage.

Like all wood-simulation colours in the StoreWALL range, Barnwood Grey will show natural variation in grain pattern and colour tone from panel to panel. This is intentional — the variation is what makes the timber simulation look convincing rather than repetitive. It also means the wall gains depth and character that a flat solid colour doesn't provide.

Because it's solid PVC, Barnwood Grey panels are fully waterproof and will never warp, swell, or rot. The texture is on the surface of the panel — it adds visual interest but does not affect the groove profile or accessory compatibility.

What's in the carton and what you'll need

The carton contains 4 Standard Duty panels covering 1.48sqm. That's what comes from StoreWALL. To complete the installation you'll also need:

• 4 × Standard Duty InstallStrips (sold separately — one per panel)
• Screws: 7g × 40mm for timber stud walls, 12 per InstallStrip (48 total)

Brick or concrete walls: 5mm × 40mm nylon mushroom anchors instead of screws, same quantity

Screws, anchors and InstallStrips are available in the store.

Installation

Standard Duty panels install using the SD InstallStrip hidden fastener system. The strip fixes to your wall first — screws into timber studs, or nylon anchors into brick or concrete — and the panel then hooks over the strip from the top and sits flush against the wall with no visible fixings and no screws through the panel face.

One SD InstallStrip per 1219mm panel — four per carton. Each 914mm strip breaks into three sections (609mm and 304mm) giving three connection points per panel. For timber stud walls, use 78g × 40mm screws, 12 per InstallStrip. For brick or concrete, use 5mm × 40mm nylon mushroom anchors, same quantity.

The Standard Duty colour range

Seven colours are available in Standard Duty. Barnwood Grey sits alongside Rustic Cedar and Whitewood as the timber-look options — Barnwood Grey in cooler grey tones, Rustic Cedar in warm red-brown, and Whitewood in a pale natural wood finish. The solid colours — Weathered Grey, Brite White, Black, and Graphite Steel — are the right choice when a clean, uniform background matters more than texture.

All seven colours are the same panel, the same grade, and the same price — the choice is purely aesthetic. All use the same CamLok accessories and SD InstallStrips.

Frequently asked questions

How many cartons do I need?

Each 1219mm carton covers 1.48sqm. For a standard double-garage wall (4m wide × 2.1m high = 8.4sqm), you would need approximately 6 cartons. Use the panel estimator on the site for your specific dimensions, or call 0411 280 646 and we'll calculate the exact quantity for your wall.

Can I add more panels to this wall later?

Yes, without removing what's already installed. Standard Duty panels connect vertically using a tongue-and-groove profile — the bottom of each new row clicks into the top of the row below. You can add rows above or below your current installation at any time, and all existing hooks and accessories stay in place while you do it.

Do I need special hooks for these panels?

No. All StoreWALL CamLok accessories fit all Standard Duty panels regardless of colour — the 30+ hooks, shelves, brackets, baskets, bins, and totes in the range are all compatible. So are accessories from MKE Milwaukee Slatwall, HandiWall, GarageTek, and GarageSmarts.

Can Standard Duty panels be cut to length?

Yes. PVC cuts cleanly with a drop saw, circular saw, jigsaw, or multi-tool with a fine-tooth blade. We also offer a free panel cutting service for orders where panels need to be trimmed before shipping. Contact us before placing the order if you need this.

Can I mix Barnwood Grey panels with other Standard Duty colours?

Yes. All Standard Duty panels have the same profile and dimensions — they connect and stack cleanly regardless of colour. Barnwood Grey pairs naturally with Weathered Grey for a tonal combination, or with Black for a high-contrast feature zone. This can be used to create contrast zones or feature rows within the same wall.

What's the difference between Standard Duty and Heavy Duty?

Standard Duty panels are 304.8mm high, 16.7mm thick, rated at 56kg at the surface. Heavy Duty panels are 381mm high, 17.7mm thick, rated at 68kg at the surface — they're taller and stronger, and use a different InstallStrip. For most Australian home garages — tools, bikes, garden equipment, general storage — Standard Duty handles everything comfortably. Heavy Duty is the right choice for trade workshops, very heavy hanging loads, gyms or large commercial installations.

What if I need help planning my installation?

Call Arthur on 0411 280 646 or email [email protected]. We'll walk you through the panel count, InstallStrip quantities, and accessory selection for your specific wall. If you'd prefer a professional installer, any carpenter or experienced handyman can complete a StoreWALL installation — no specialist training required.

Notes:

Brite White - The Whiteness of the Brite White panel may vary between batches. We will make every effort to ensure your order comes from the same batch.

Graphite Steel - is a unique metallic surface treatment, very similar to that found on an automobile. The substructure is solid PVC as are all storeWALL slatwall panels. Please note the metallic effect is only on the surface and if gouged deep enough, just like an automobile, the gouge may show. Thus we encourage reasonable care and handling be exercised when choosing our Graphite Steel slatwall panels.

Weathered Grey - Our Weathered Grey finishes are made as solid colour slatwall but do have a painted finish on the surface. This is to eliminate common streaking in the extrusion process that is only found in grey extruded plastic. The painted finish results in a even consistent finish.

Rustic Cedar, Global Pine, and Barnwood Grey - are intended to simulate real wood; and like real wood there might be some variation in grain and tint from panel to panel.
