StoreWALL Standard Duty Wall Panels are ideal for just about every use around the home, garage and even workshop. StoreWALL slatwall panels are waterproof, versatile and significantly stronger than most storage or slatwall panels currently available in Australia.
Standard Duty Wall Panels – Panel Sizes
The StoreWALL Standard Duty Wall Panels are available in two sizes, 1219 mm and 2438 mm. Slatwall dimensions include:
- Each 1219mm slatwall panel has the following dimensions: 1219mm in length x 304mm x 16.7mm in thickness. The total coverage for each panel is .37m squared.
- Each 2438mm slatwall panel has the following dimensions: 2438mm in length x 304mm x 16.7mm in thickness. The total coverage for each panel is .74m squared.
Our slatwall panels are sold in Kits. The 1219mm kit comes with 4 slatwall panels covering a total area of 1.48m squared. The 2438mm kit comes with 4 slatwall panels covering a total area of 2.96m squared.
We recommend that you utilise our InstallStrips for a more secure installation. Each 914mm InstallStrip-SD can be separated into 609mm or 304mm sections to provide a truly customisable installation.
Recommendation: One InstallStrip-SD for EACH 1.2m panel (qty 4 InstallStrip-SD for one case of 1.2m panels). Two InstallStrip-SD for EACH 2.4m panel (qty 8 InstallStrip-SD for one case of 2.4m panels).
Wall Strength (2438mm Panel)
Below specifications relate to a single 2438mm panel which is installed with 2 x installstrips (6 connections points along the length of the panel). Weight to be distributed along the length of the panel with multiple accessories.
- 113kg at the panel surface
- 52kg at 10cm from the surface of the wall
Colour Range
The Standard Duty Wall Panel colour range includes Weathered Grey, Brite White, Barnwood Grey, Whitewood, Rustic Cedar, Graphite Steel and Black.
Find Storewall slatwall panel specifications here.
Find Storewall slatwall panel brochure here,
