The StoreWALL Heavy Duty 254mm Bracket is one of the most versatile accessories in the range — use it to build floating wall shelves, store bikes horizontally, or support timber, containers and other large items directly on the bracket arm. Solid powder-coated steel with CamLok™ pre-installed, each bracket locks securely into any StoreWALL slatwall panel and repositions tool-free in seconds.
Pair with StoreWALL's floating plastic or metal shelves for a ready-made solution, or build your own shelf up to 254mm deep using the two drill holes on the bracket arm. Sold individually — minimum two brackets required per shelf.
What Can the 254mm Bracket Do?
- Floating garage shelves — pair two or more brackets to support StoreWALL plastic shelves, metal shelves or your own timber cut to size
- Horizontal bike storage — store bikes flat against the wall, frame resting on padded brackets. Add optional foam non-slip padding to protect your bike frame
- General storage — support timber offcuts, containers, sports equipment and workshop supplies directly on the bracket arm
How Many Brackets Do I Need for a Shelf?
- Up to 1.2m wide — use at least 2 brackets
- Up to 1.8m wide — use at least 3 brackets
- Up to 2.4m wide — use at least 4 brackets
Maximum shelf depth: 254mm. If building your own shelf, ensure the material does not exceed this depth. The bracket has two drill holes for secure shelf attachment.
Specifications
← Swipe for full table →
| Specification | Detail |
|---|---|
| SKU | BR-HD10 |
| Length | 254mm |
| Load rating per bracket | 34kg |
| Load rating per pair | 68kg — panels installed with InstallStrips, brackets spaced up to 1.2m apart |
| Maximum shelf depth | 254mm |
| Material | Solid powder-coated steel |
| Panel compatibility | Standard Duty, Heavy Duty StoreWALL panels, and MKE Slatwall panels |
| Mounting | CamLok™ pre-installed — quarter-turn locking, tool-free repositioning |
| Optional extra | Foam non-slip padding (+$2.50) — add at checkout to protect bike frames and prevent shelf items sliding |
| Sold as | Single bracket — minimum 2 required per shelf |
Compatible Shelves
- 812mm Floating Plastic Shelf — designed to fit the 254mm bracket; no cutting required
- 1219mm Floating Plastic Shelf — full panel width; suits a 2-bracket setup at 1219mm spacing
- Custom timber, MDF or metal shelving cut to a maximum depth of 254mm
Need More Depth?
The Heavy Duty 381mm Bracket offers more reach at 381mm for deeper shelving applications and the 400mm Deep Floating Metal Shelf. Note: the 254mm and 381mm brackets are not interchangeable with the floating shelves — each shelf requires its matching bracket size.
