StoreWALL Bike Hook — J-Hook Vertical Garage Bike Storage
The simplest and most affordable way to get a bike off your garage floor. The J-Hook hangs any bike with spoked wheels vertically from the front wheel — mount it to your StoreWALL panels, lift the front wheel onto the hook, and the bike hangs securely against the wall. At $28.99 it's the entry point for wall-mounted bike storage, and at 45kg capacity it handles any standard bike including heavier e-bikes.
The bike hangs perpendicular to the wall. If floor space is tight and you need the bike to sit flat against the wall instead, the Rotating J-Hook adds a swivel mechanism for that purpose. CamLok™ pre-installed. Sold as a single hook.
Specifications
← Swipe for full table →
| Specification | Detail |
|---|---|
| SKU | HK-J |
| Dimensions | 95mm H × 70mm W × 127mm D |
| Weight capacity | 45kg — panels installed with InstallStrips |
| Mounting | CamLok™ pre-installed — locks directly into StoreWALL slatwall grooves |
| Panel compatibility | Standard Duty, Heavy Duty StoreWALL panels, and MKE Slatwall panels |
| Bike compatibility | Any bike or trike with spoked wheels |
| Storage orientation | Vertical — bike hangs perpendicular to the wall from the front wheel |
| Repositionable | Yes — quarter-turn CamLok releases and relocks tool-free |
| Sold as | Single hook |
What bikes suit the J-Hook
- Road bikes and racing bikes — narrow tyres hang cleanly with minimal contact
- Hybrid and commuter bikes — most popular everyday use case
- Mountain bikes — wider tyres still fit the hook profile. For extra tyre support consider the Mountain Set
- Kids' bikes — lightweight, easy to lift onto the hook
- E-bikes — 45kg capacity handles most e-bikes comfortably
- Trikes with spoked wheels — any bike with a conventional front wheel
J-Hook vs Rotating J-Hook — which to choose
The J-Hook stores the bike perpendicular to the wall — the bike sticks out into the garage at roughly its full length (1.5–1.8m). The Rotating J-Hook does the same thing but adds a swivel, letting you rotate the bike flat against the wall after hanging — reducing the floor clearance needed from 1.5–1.8m to just 200–300mm.
If floor space isn't a constraint, the J-Hook at $33.99 is the simpler, more affordable option. If you're fitting multiple bikes into a tight garage, the Rotating J-Hook's space saving justifies the price difference.
Frequently asked questions
How high should I mount the hook?
High enough that the front wheel clears the floor when the bike is hanging. For a standard adult bike this is typically 1.3–1.6m from the floor to the hook, depending on wheel size. Mount it, hang the bike, check clearance, then lock CamLok.
Will it work for a mountain bike with wide tyres?
Yes — the J-Hook accommodates standard MTB tyre widths. For very wide tyres or e-MTBs where you want additional lower tyre support, the Mountain Set includes a Wide Hook for lower support alongside the main hook.
Is one hook enough per bike?
Yes — one J-Hook per bike. The front wheel hangs from the hook and the rear wheel rests near the floor or just above it depending on hook height. If you want lower tyre support as well, consider the Classic Set which adds a Universal Hook for the lower tyre.
Is it compatible with all StoreWALL panels?
Compatible with Standard Duty, Heavy Duty StoreWALL panels, and MKE Slatwall panels. The CamLok fits the same 76mm on-centre groove pitch across all three.
